Quick Details

  • Place of Origin: Zhejiang, China (Mainland)
  • Brand Name: XINE
  • Model Number: ABC
  • Insulation Material: HDPE or XLPE or Weather -proof PVC
  • Conductor Material: Aluminum
  • Jacket: None
  • Certification: ISO,CCC
  • Insulation material: HDPE or XLPE or Weather-proof PVC
  • Color: black
  • Shielding: Non-Shielded

Packaging & Delivery

Packaging Details In standarded export wooden drums.
Delivery Time 20 days for a 20FT container.
ABC Cable
Aerial bundled cable
Standard and application scope:
This product is produced in accordance with the standard of IEC60502/BS 2627. The products,Cu core or Al core XLPE or HDPE aerial insulated electric power cable,may be used the fields where the A.C.rated voltage U(Um) is 0.6/1kV.
Using feature:
1) The max long-term operating temperature of cable conductor(cable having supporting structure):
a) XLPE insulation :90°C
b) HDPE insulated 75°C
2) When short circuit (the Max. lasting time is not over 5 seconds), the Max.temperature of the cable:
a)XLPE insulated: 250°C
b)HDPE insulated 150°C
3) When laying, the temperature should not be lower than -20oC;
4) The permitted bend radius should not be less than the diameter of cylinder that had been used for the bend testing.
5) Cables installed in air;
6) Ambient temperature:40oC
7) Intensity of solar radiation:1000w/m2
Type of the cable:
Type
DesignationMain Application
JKYJ
Cu core XLPE aerial insulated cable
Aerial and fixed laying. The product of soft copper is used for leading wire of transformer. When laying, a certain distance must be kept between the cable and the tree. When operation, the cable can contact with the tree equently.
JKTRYJ
Soft Cu core XLPE aerial insulated cable
JKLYJ
Al core XLPE aerial insulated cable
JKY
Cu core PE aerial insulated cable
JKTRY
Soft Cu core PE aerial insulated cable
JKLY
Al core PE aerial insulated cable
JKLYJ/B
Al core with essential color XLPE aerial insulated cable
Aerial and fixed laying. When laying, a certain distance must be kept between the cable and the tree. When operation, the cable can contact with the tree in a short time.
JKLYJ/Q
Al core light XLPE aerial insulated cable
JKLY/Q
Al core light PE aerial insulated cable
JKLGYJ
Al conductor steel-reinforced XLPE aerial insulated cable
JKLGYJ/Q
Al conductor steel-reinforced light XLPE aerial insulated cable
((aerial branched cable,aerial bundled cable,Aerial Insulated Cable, ABC)


Our company&factory

Certificate







Production Line







Factory
